Okvir
Ransom Carbon HMF Mainframe with Alloy 6061 Swingarm#Integrated Suspension Technology#6 Link kinematic / Adjustable head angle#Syncros Cable Integration System#BB92 / UDH Interface / 12x148mm with 55m
Vilice
RockShox Domain R Solo Air#15x110mm Maxle stealth axle#42mm offset / Tapered Steerer#Reb. Adj. / 170mm travel
Zadnje vzmetenje
FOX FLOAT X NUDE EVOL Piggy Back Trunnion / SCOTT custom w. travel / geo adj.#3 modes: Climb-Ramp Control-Descend#Custom large Air volume / Comp & Reb. Adj.#Travel 170-130-Climb / T205X65mm / Bearing
Sistem za nastavitev amortizerjev
TracLoc Technology#Rear Suspension & Dropper Remote#3 Rear Suspension modes
Zadnji menjalnik
Shimano Deore RD M6100 / 12 Speed
Prestavna ročica
Shimano Deore SL-M6100-R / Rapidfire Plus
Hod
SPREDNJI: 170 mm, ZADNJI: 170 mm
Napere
Stainless Black 15G / 1.8mm
Nosilec krmila
Syncros AM 2.0#Syncros Cable Integration System#4° rise / 6061 Alloy / 31.8mm / 40mm
Pesto
SP: Formula CL 811 / 15x110mm, ZAD: Formula CL 148M / Boost 12x148mm / Micro Spline
Verižnik
Shimano Deore CS-M6100-12 / 10-51 T
Gonilka
Shimano FC MT512#32T / Chainline 55mm
Vodilo verige
SCOTT custom
Gonilni ležaj
Shimano BB-MT500-PA / shell 41x92mm
Kaseta
Shimano Deore CS-M6100-12 / 10-51 T
Zavore
Shimano MT520 4 Piston Disc
Rotor
Shimano SM-RT64 / centerlock / 203mm
Krmilo
Syncros Hixon 2.0 Alloy 6061 D.B.#Size S & M 12mm Rise / Size L & XL 20mm Rise / back sweep 8° / 780mm#Syncros Endurance lock-on grips
Sedežna opora
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm#S size 140mm / M size 180mm / L & XL size 210mm
Sedež
Syncros Tofino 2.0#Crmo Rails
Krmilni ležaj
Syncros - Acros Angle adjust & Cable Routing HS System#+-0.6° head angle adjustment#ZS56/28.6 – ZS56/40 MTB
Obroči
Syncros X-30S / 32H / 30mm / Sleeve Joint#Tubeless ready
Platišča
P: Maxxis Assegai / 2.5" / 60TPI Foldable#EXO / TR / Dual, Z: Maxxis Dissector / 2.4" / 120TPI Foldable / DD/ TR / 3C Maxx Terra
Pogon
SRAM CN GX Eagle Transmission
