Okvir
Carbon HMF#Integrated Suspension Technology#Virtual 4 Link kinematic / Adjustable head angle#Syncros Cable Integration System#TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline#Range Extender Rea
Vilice
FOX 36 Float Rhythm Air Grip#3 modes / 15x110mm QR axle / tapered steerer#44mm offset / Reb. Adj. / Lockout / 160mm travel
Zadnje vzmetenje
FOX NUDE 6T EVOL Trunnion#SCOTT custom w. travel / geo adj.#3 modes: Lockout-Traction Control-Descend#Low Speed Adj. / Custom large Air volume / Reb. Adj.#Travel 155-100-Lockout / T185X55mm
Sistem za nastavitev amortizerjev
SCOTT TwinLoc 2 Technology#Suspension & Dropper Remote#3 Suspension modes
Zadnji menjalnik
Shimano XT RD-M8100 SGS#Shadow Plus / 12 Speed
Prestavna ročica
Shimano Deore SL-M6100-IR / Rapidfire Plus#I-spec EV clamp
Hod
Front: 160mm / Rear: 155mm
Napere
Stainless Black 15G / 1.8mm
Nosilec krmila
Syncros AM 1.5#Syncros Cable Integration System#4° rise / 7050 Alloy / 31.8mm / 1 1/8"
Pesto
SP: Formula CL-811 / 15x110mm, ZAD: Formula CL-148M / 12x148mm
Verižnik
Scott custom spider / FSA 12Speed 34T chainring
Zaslon
TQ HPR#Bluetooth / ANT+ / Dedicated Smartphone app
Gonilka
FSA Alloy crankset / 175mm / 34T
Vodilo verige
e*thirteen / e*spec Slider
Kaseta
Shimano CS-M6100 / 10-51T
Zavore
Shimano Deore M6120 4 Piston Disc
Rotor
Shimano SM-RT64 CL / F&R 203mm
Krmilo
Syncros Hixon 1.5 Alloy 7050#Size S & M 15mm rise / Size L & XL 25mm rise#back sweep 8° / 780mm#Syncros Endurance lock-on grips
Sedežna opora
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm#S size 140mm / M size 180mm / L size 210mm
Sedež
Syncros Tofino 1.5 Regular#Titanium rails
Krmilni ležaj
Syncros - Acros Angle adjust & Cable Routing HS System#Stainless / +-0.6° head angle adjustment#ZS56/28.6 – ZS56/40 MTB
Obroči
Syncros X-30S / 32H / 30mm / Sleeve Joint#Tubeless ready
Platišča
P: Maxxis Dissector / 2.6" / 60TPI Foldable#Tubeless Ready / EXO 3C maxx Terra, Z: Maxxis Dissector / 2.6" / 60TPI Foldable#Tubeless Ready / EXO 3C maxx Terra
Pogon
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Baterija
TQ Internal 360Wh
