Okvir
Carbon HMF#Integrated Suspension Technology#Virtual 4 Link kinematic / Adjustable head angle#Syncros Cable Integration System#TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline#Range Extender Rea
Vilice
Marzocchi Z2 Air Rail#3 modes / 15x110mm QR axle / tapered steerer#44mm offset / Reb. Adj. / Lockout / 150mm travel
Zadnje vzmetenje
FOX Float Custom EVOL Performace Trunnion#3 modes / Lockout-Trail-Descend#DPS / Reb. Adj.#Travel 155mm / T185X55mm
Sistem za nastavitev amortizerjev
SCOTT TwinLoc 2 Technology#Suspension & Dropper Remote#3 Suspension modes
Zadnji menjalnik
Shimano XT RD-M8100 SGS#Shadow Plus / 12 Speed
Prestavna ročica
Shimano Deore SL-M6100-IR / Rapidfire Plus#I-spec EV clamp
Hod
Front: 150mm / Rear: 155mm
Napere
Stainless Black 15G / 1.8mm
Nosilec krmila
Syncros AM 2.0#Syncros Cable Integration System#4° rise / 6061 Alloy / 31.8mm / 1 1/8"
Pesto
SP: Formula CL-811 / 15x110mm, ZAD: Formula CL-148M / 12x148mm
Verižnik
Scott custom spider / FSA 12Speed 34T chainring
Zaslon
TQ HPR#Bluetooth / ANT+ / Dedicated Smartphone app
Gonilka
FSA Alloy crankset / 175mm / 34T
Vodilo verige
e*thirteen / e*spec Slider
Kaseta
Shimano CS-M6100 / 10-51 T
Zavore
SRAM DB8 4 Piston Disc
Rotor
SRAM Centerline CL Rotors F&R 200mm
Krmilo
Syncros Hixon 2.0 Alloy 6061 D.B.#12mm Rise / back sweep 8° / 780mm#Syncros Endurance lock-on grips
Sedežna opora
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm#S size 140mm / M size 180mm / L & XL size 210mm
Sedež
Syncros Tofino 2.0 Regular
Krmilni ležaj
Syncros - Acros Angle adjust & Cable Routing HS System#Stainless / +-0.6° head angle adjustment#ZS56/28.6 – ZS56/40 MTB
Obroči
Syncros X-30S / 32H / 30mm / Sleeve Joint#Tubeless ready
Platišča
P: Maxxis Dissector / 29x2.6" / 60TPI Wire Bead#EXO#Dual, Z: Maxxis Dissector / 29x2.6" / 60TPI Wire Bead#EXO#Dual
Pogon
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Baterija
TQ Internal 360Wh
