Okvir
Carbon HMF#Integrated Suspension Technology#Virtual 4 Link kinematic / Adjustable head angle#Syncros Cable Integration System#TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline#Range Extender Rea
Vilice
FOX 36 Float Factory Grip 2 Air / Kashima#HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle#44mm offset / tapered steerer#160mm travel
Zadnje vzmetenje
FOX FLOAT X NUDE Factory EVOL Piggy Back Trunnion#Kashima / SCOTT custom w. travel / geo adj.#3 modes: Climb-Ramp Control-Descend#Custom large Air volume / Comp & Reb. Adj.#Travel 155-100-Climb / T185
Sistem za nastavitev amortizerjev
TracLoc Technology#Rear Suspension & Dropper Remote#3 Rear Suspension modes
Zadnji menjalnik
SRAM GX Eagle AXS Transmission 12 Speed#Wireless Electronic Shift System
Prestavna ročica
SRAM GX Eagle AXS Rocker Controller
Hod
Front: 160mm / Rear: 155mm
Verižnik
Scott custom spider / SRAM Eagle Transmission 34T chainring
Zaslon
TQ HPR#Bluetooth / ANT+ / Dedicated Smartphone app
Gonilka
e*thirteen / e*spec Race Carbon / 34T
Vodilo verige
e*thirteen / e*spec Slider
Veriga
SRAM CN GX Eagle Transmission
Kaseta
SRAM GX Eagle XS 1275 Transmission 10-52
Zavore
SRAM Code Silver Stealth 4-Piston Disc
Rotor
SRAM HS2 Rotors F&R 200mm
Krmilo
Syncros Hixon iC Carbon#Size S & M 15mm rise / Size L & XL 25mm rise#back sweep 8° / 780mm#Syncros Endurance lock-on grips
Sedežna opora
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm#S size 140mm / M size 180mm / L & XL size 210mm
Sedež
Syncros Tofino 1.5 Regular#Titanium rails
Krmilni ležaj
Syncros - Acros Angle adjust & Cable Routing HS System#Stainless / +-0.6° head angle adjustment#ZS56/28.6 – ZS56/40 MTB
Obročniki
Syncros Revelstoke 1.0-30 CL#F: 15x110mm#R: 12x148mm#30mm Tubeless ready Carbon rim 28H#DT Swiss Ratchet Hubs / XD Driver#SRAM TyreWiz / Syncros Axle w/Removable Lever#with 6mm Allen#T30 and T25 Tools
Platišča
P: Maxxis Assegai / 2.6" / 60TPI Foldable#Tubeless Ready / EXO+ 3C maxx Terra, Z: Maxxis Dissector / 2.6" / 60TPI Foldable#Tubeless Ready / EXO+ 3C maxx Terra
Pogon
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Baterija
TQ Internal 360Wh
