Okvir
Carbon HMF Main Frame / Alloy SST-CST#Integrated Suspension Technology#Flex Pivot / Adjustable head angle#Syncros Cable Integration System#TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Vilice
FOX 34 Float Rhythm Air Grip#3 modes / Kabolt 15x110mm axle / tapered steerer#44mm offset / Reb. Adj. / Lockout / 130mm travel
Zadnje vzmetenje
FOX NUDE 6T EVOL Trunnion#SCOTT custom w. travel / geo adj.#3 modes: Lockout-Traction Control-Descend#Low Speed Adj. / Custom large Air volume / Reb. Adj.#Bearing Hardware / Travel 130-90-Lockout / T1
Sistem za nastavitev amortizerjev
SCOTT TwinLoc 2 Technology#Suspension & Dropper Remote#3 Suspension modes
Zadnji menjalnik
Shimano XT RD-M8100 SGS#Shadow Plus / 12 Speed
Prestavna ročica
Shimano Deore SL-M6100-IR / Rapidfire Plus#I-spec EV clamp
Hod
Front: 130mm / Rear: 130mm
Napere
Stainless Black 15G / 1.8mm
Nosilec krmila
Syncros DC 2.0#Syncros Cable Integration System#0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Pesto
SP: Formula CL-811 / 15x110mm, ZAD: Formula CL-148M / 12x148mm / Micro Spline#Syncros Axle w/Removable Lever#with 6mm Allen#T30 and T25 Tools
Verižnik
Scott custom spider / FSA 12Speed 34T chainring
Zaslon
TQ HPR#Bluetooth / ANT+ / Dedicated Smartphone app
Gonilka
FSA Alloy crankset / 175mm / 34T
Vodilo verige
e*thirteen / e*spec Slider
Kaseta
Shimano CS-M6100 / 10-51 T
Zavore
Shimano Deore M6120 4 Piston Disc
Rotor
Front: SM-RT64 CL 180mm / Rear: RT-EM600 CL 180mm
Krmilo
Syncros Fraser 2.0 DC Alloy 6061 D.B.#mini Rise / back sweep 8° / 760mm#Syncros Performance XC lock-on grips
Sedežna opora
Syncros Duncan Dropper Post 2.0#31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
Sedež
Syncros Tofino 2.0 Regular#CRMO rails
Krmilni ležaj
Syncros - Acros Angle adjust & Cable Routing HS System#+-0.6° head angle adjustment#ZS56/28.6 – ZS56/40 MTB
Obroči
Syncros X-30SE / 32H / 30mm#Tubeless ready
Platišča
P: Schwalbe Wicked Will 29x2.4" EVO#Super Race / TLE / 67EPI / Addix Speed Soft, Z: Schwalbe Wicked Will 29x2.4" EVO#Super Race / TLE / 67EPI / Addix Speed Grip
Pogon
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Baterija
TQ Internal 360Wh
